OMP Hydraulic Motor – RYLSUN Hydraulic Orbital Motor

Reliable and Efficient RYLSUN OMP Hydraulic Motor

The RYLSUN OMP Hydraulic Motor is designed to deliver reliable, efficient, and long-lasting performance for a wide range of hydraulic applications. Built using a durable cast iron housing and precision-engineered internal components, the motor ensures smooth operation even in demanding industrial and mobile equipment environments.

Hydraulic orbit motors are widely used in mobile and industrial hydraulic systems because of their compact design and high torque efficiency. The compact orbital motor design makes it suitable for applications where space-saving installation and high torque performance are important.

The RYLSUN OMP hydraulic motor features an advanced integral rotor and stator design that improves operational efficiency and enhances durability. This design helps provide stable low-speed, high-torque performance with reduced vibration and noise levels. The motor is engineered to maintain consistent power output and dependable functionality under continuous operating conditions.

Manufactured according to ISO9001:2015 quality standards and compliant with CE and RoHS requirements, RYLSUN ensures high manufacturing quality and product reliability. Every hydraulic motor undergoes strict quality inspection and testing before dispatch to ensure excellent performance and long service life. The motor is also supported by a one-year warranty for added customer confidence.

Description
Reviews (0)

Type		OMP-50	OMP-100	OMP-160	OMP-200	OMP-250
Geometric Displacement		51.7	96.2	157.2	194.5	240.3
Max. speed (rpm)	Rated	850.0	520.0	310.0	260.0	200.0
	Continuous	1150.0	615.0	383.0	310.0	250.0
	Intermittent	1450.0	770.0	475.0	385.0	310.0
Max. torque (N.m)	Rated	81.0	161.0	204.0	259.0	325.0
	Continuous	100.0	182.0	302.0	360.0	380.0
	Intermittent	128.0	227.0	370.0	440.0	460.0
	Peak	148.0	264.0	434.0	540.0	550.0
Max. output (kW)	Continuous	10.0	11.0	10.0	10.0	8.5
Max. output (kW)	Intermittent	12.0	13.0	12.0	12.0	10.5
Max. pressure drop (MPa)	Rated	12.5	12.5	10.0	10.0	10.0
	Continuous	14.0	14.0	14.0	14.0	11.0
	Intermittent	17.5	17.5	17.5	17.5	14.0
	Peak	22.5	22.5	22.5	22.5	18.0
Max. flow (L/min)	Rated	45.0	55.0	55.0	55.0	55.0
	Continuous	60.0	60.0	60.0	60.0	60.0
	Intermittent	75.0	75.0	75.0	75.0	75.0
Weight (kg)		6.0	6.0	6.2	6.4	7.0

Applications of RYLSUN OMP Hydraulic Motor

The RYLSUN OMP hydraulic motor is widely used in agricultural machinery, packaging machines, material handling systems, conveyors, sweepers, small construction equipment, and industrial hydraulic systems. Its compact structure and efficient hydraulic performance make it suitable for both mobile and stationary hydraulic applications.

The motor is available in multiple displacement options, allowing users to select the right configuration according to speed and torque requirements. With a maximum working pressure of up to 140 bar, the RYLSUN OMP hydraulic motor offers dependable performance for continuous-duty applications.

OEMs, hydraulic equipment manufacturers, and system integrators prefer the RYLSUN OMP Series because of its durability, cost-effectiveness, and easy installation. The motor’s compact construction also helps simplify integration into hydraulic power systems where installation space is limited.

Features of RYLSUN OMP Hydraulic Motor

1. Compact Design

The compact integral rotor and stator construction helps reduce overall motor size and weight. This makes the RYLSUN OMP hydraulic motor ideal for equipment where installation space is limited. The lightweight and compact structure also contributes to easier handling and installation.

2. High Efficiency

The advanced rotor-stator technology and precision manufacturing process ensure excellent hydraulic efficiency and strong torque output. The motor delivers smooth power transmission with reduced energy loss, helping improve overall machine performance and productivity.

3. High Pressure Capability

The high-quality shaft seal system is designed to withstand elevated pressure conditions and maintain reliable sealing performance. This allows the motor to operate efficiently in both series and parallel hydraulic circuits while minimizing the risk of oil leakage.

4. High Power Density

The advanced hydraulic motor design provides high power output relative to its compact size. This high power density helps improve machine efficiency while maintaining compact equipment dimensions.

5. Cost-Effective Hydraulic Solution

The RYLSUN OMP hydraulic motor offers an excellent balance of durability, efficiency, and affordability. Its robust construction, low maintenance requirements, and long service life make it a practical and economical choice for various hydraulic applications.

6. Low Maintenance Operation

The RYLSUN OMP hydraulic motor is designed for reliable long-term operation with minimal maintenance requirements. Its durable internal components and precision sealing system help reduce wear, improve operational stability, and minimize downtime in demanding hydraulic applications.

Why Choose RYLSUN OMP Hydraulic Motor?

RYLSUN focuses on delivering dependable hydraulic solutions with consistent quality, durability, and reliable performance. Designed for long operational life and minimal maintenance, the RYLSUN OMP hydraulic motor is a trusted solution for industrial and mobile hydraulic systems. With strong construction, efficient operation, and versatile applications, the RYLSUN OMP Series hydraulic motor provides excellent value for customers seeking reliable hydraulic power solutions.

For product specifications, pricing, and bulk order inquiries, please visit our Contact Us page or get in touch with the RYLSUN team for expert hydraulic solution support.
